WHAT IS AN FMODtm ?

THE FMOD IS AN ACTIVE CROSSOVER SIMULATOR. IT IS BETTER THAN A MUCH MORE EXPENSIVE ELECTRONIC CROSSOVER THAT REQUIRES POWER TO OPERATE. FMODS ARE PACKAGED IN PAIRS AND AN FMOD CAN BE COMBINED WITH OTHER TYPES OF CROSSOVERS TO CHANGE THE SLOPE (DB/OCTAVE) AND CROSSOVER FREQUENCY POINT.



WHY ARE FMODS BETTER?



FMODS HAVE VIRTUALLY NO NOISE OR DISTORTION



FMODS DO NOT CAUSE TURN ON THUMPS



FMODS ARE VERY RELIABLE



FMODS ARE 24KT GOLD OVER BRASS



FMODS ARE COLOR CODED AND

MADE BY HLABS IN THE U.S.A.



12 DB/ OCTAVE

20 to 1000 Hz
VALUES
VALUES
20 to 1000 Hz
VALUES
VALUES
$27.50 per pair

SPECIFICATIONS

GOLD OVER MACHINED BRASS

RCA JACKS 0.4” O.D. X 2” LONG



20 VOLTS RMS MAXIMUM

STD. DRIVING IMPEDANCE 600Ω



MAXIMUM DRIVING IMPEDANCE 10,000Ω (10KΩ)



NOISE AND DISTORTION TOO LOW TO MEASURE



ACCURACY ± 1% @ 22KΩ LOAD

FOR CUSTOM VALUES $50 PER PAIR
